Technical Parameter:

Input Voltage:          AC 220/380V

Frequency:               50/60Hz

Max. Current:           7000A

Rated Power:           10KVA

Max. Power:             50KVA

Insulation Grade:      F

IP Grade：                IP21

Air Pressure：          1.0Mpa

Output Voltage：     2-13V

Welding Thickness：1.0+1.5mm

2.5+2.5mm

Cable:                        2*3m*150mm²

Cable:                        2*2.5m*75mm²

Package Size:            62*68*120cm

Weight:                     145kg
