Technical Parameter:

Input Voltage:                    AC 220/380V

Frequency:                         50/60Hz

Rated Power:                     5KVA

Fuse:                                  10A

Welding Current:               15-270A

Duty Cycle:                         35%

Insulation Grade:                F

Wire Diameter:                   0.8 / 1.0mm

Wire Feeding Mechanism:  inner

Package Size:                      470*770*790cm

Weight:                               70KG

• For all position fast welding and electric welding of thin plate to medium plate, suitable for welding soft steel, low alloy structural steel, high strength steel of Di alloy, etc.
• This machine has an integrated structure, wire feeding circuit using pwm carving, wire feeding force is large, effectively ensure the smooth wire feeding speed in the welding process.
• Adjust the welding time and intermittent time on the panel, this function is designed for sheet spot welding, no need for long seam welding use.
• This machine is widely used in steel structure, petrochemical, automobile, shipbuilding, machinery manufacturing and so on.
• Unique automatic detection of power grid voltage function, multi-layer bridge rectifier, equipped with heating decompression meter.
